Home / obd Right Angle connector
Model Number: YH1006-3
Certification: ROHS, REACH
Minimum Order: 100pcs
Delivery Time: About 20days
Payment Terms: T/TWestern Union
Supply Ability: 20000 pieces per month
★YH1006-3 obd2 plug angle connector Car Diagnostic Connectors turn the cable sideways and create more leg room while the port is in use.
★This OBDII right angle connector is widely used on Fleet management system， GPS Tracker, M2M Device, UBI Telematics(Usage Based Car-Insurance)...
★This J1962 right angle male 16pin obdii connector is deal if you need to drive with an obdii scanner plugged in.
★It is portable, compact and easy to use.
★High-quality materials and quality craftsmanship give the cable superior flexibility and durability
★Connecting OBD II 16 Pin diagnostic tool and all series vehicle with obdii port
★Our products with a wide range, superior quality, reasonable price and stylish designs
Much equipment will use YH1006-3 obdii J1962 right angle male connector. Such as an Telematic Safety Devices, Fleet management system,Fleet management system， GPS Tracker, M2M Device, UBI Telematics(Usage Based Car-Insurance),Smart network infrastructure, aircraft safety devices,EOBD/OBDII diagnostics information reader, EOBD universal diagnostic tester, OBD-CAN programming tool, Omegas unit with OBD, OBD simulator, OBD 2 scanner, OBD core reader, OBD II scanner, electronic controller, telematics.
| Connector Specification | |
| Over molded color | Black & customized |
| Core color | Black Red, Green, Blue |
| Core material | ABS |
| Terminals' material | Brass Nickel plated |
| Terminals' Part No. | YH OBD-01 |
| Terminals Applied Optical cable | SOLDER |
| Plug test | over 50000 times |
| Wire Specification | |
| Cable length | 200mm & customized |
| Cable jacket | PVC,PUR and Customized |
| Cable pin out | Customized |
| Cable cross-section | AWG 26-20 available |
| Cable Bending testing life | NO |
| Electronic parameter | |
| Withstand Voltage | 300V DC |
| Insulation Resistance | Over 2MΩ |
| Rated current | 1A ~ 5A |
| Contact Resistance | MAX 1Ω (L≤3M) |
| Wire Rated temperature | -20 ~ 105 ℃ |
● YH1006-3 obdii right angle plug are widely used in all series cars.
● According to your electronic layout, cable length and wire structure requirement, our engineer will send the DWG for your confirm.
● This items cable be mass production only get your confirmed about our DWG.
● Before shipment, we will do 3 times 100% test and inspection for this item.
● Our sales service of before and after-sales will satisfied with you.
● We have full ability to offer customer obd2 male connector, obd2 female connector, J1962 plug/socket, obd2 adapter/converter..
