obd2 16 pin male to deutsch hd 9 pin male green truck diagnostic cable

Model Number: YH1002 to YHHD10-9-1939P-P080
Certification: ISO9001: 2015, ROHS, REACH
Minimum Order: 100pcs
Delivery Time: About 20days
Payment Terms: T/T Western Union
Supply Ability: 30000 pieces per month

Features

Obd2 16 pin male to deutsch hd 9 pin male green truck diagnostic cable. SAE J1708 is the vehicle bus recommended practice used for communication and diagnostics among vehicle components, originally by the car and heavy-duty truck industry in the United States.

The original Part No. of this type Deutsch 9pin connector is YHHD10-9-1939P-P080.

It has integrated the basic diagnostic functions of 1708 heavy duty truck standard communication protocols.

Specializes in manufacturing connector more than 11 year as well as export the relevant component.

These years, our company make great efforts to improve the technique of production through using advanced equipment.

Application


Obd2 16 pin male to deutsch hd 9 pin male green truck diagnostic cable can be used in J1708 CAN BUS diagnostic unit (for trucks), J1708 body builder CAN bus monitor (for trucks), J1708 interface industrial engine display unit, ISOBUS-control devices, can bus Universal Controller, CAN gateway and bus simulator, truck diagnostic tool/equipment/scanner, automotive diagnostic equipment, automotive scanner….


products specification
Wire Specification
Cable length 200mm & customized
Cable jacket PVC
Cable pinout Customized
Cable cross-section UL2651 16 Pin 24-28 AWG flat wire (pitch=1.27mm)
Cable Bending testing life NO
Terminals Applied Optical cable NO
Plug test
Electronic Parameter
Withstand Voltage 300V DC
Insulation Resistance Over 2MΩ
Rated current 1A ~ 3A
Contact Resistance MAX 1Ω (L≤3M)
Wire Rated temperature -20 ~ 105 ℃
Advantages
Yeahui

● Deutsch 9pin J1708 male connector to OBDII Female truck cable can be used in diesel engine.

● According to our drawings or samples, we have full ability to provide a finished Deutsch wire harness.

● Overmolding Deutsch J1708 Deutsch 9pin receptacle to OBDII male cable will be more durable.

● The raw material of J1708 connector and OBDII Female connector must through extremely strict testing before store in our warehouse.

● Strict Quality Control System in Yeahui and all obd connector and cables should be 100% inspected before dispatching.
