YH6003 Truck Trailer Connector J1708 CAN BUS Diagnostic Unit 6-Way Round Plug

Model Number: YH6003
Certification: ROHS, REACH
Minimum Order: 100pcs
Delivery Time: About 20days
Payment Terms: T/TWestern Union
Supply Ability: 20000 pieces per month


Features

YH6003 Truck Trailer Connector J1708 CAN bus diagnostic unit 6 way round plug can now be found in a range of diesel-powered applications: vehicles (on- and off-road), marine propulsion, power generation and industrial pumping.

It has integrated the basic diagnostic functions of 1708 heavy duty truck standard communication  protocols.

The original Part No. of this type Deutsch 6pin connector is HD10-6-12P-L

There are various type Deutsch 6pin connector in our factory, such as HD16-6-12S-B010, HD16-6-12S, HD10-6-12P-L, DT06-6S, DT04-6P…

SAE J1708 is the vehicle bus recommended practice used for communication and diagnostics among vehicle components, originally by the car and heavy-duty truck industry in the United States. The Deutsch 9pin connector is according to the standard of SAE J1708.

We will design truck (Deutsch )wire harness for you when you let us know the specification of the cable, connector’s Part No., pinout assignment, cable length….

Specializes in manufacturing connector more than 10 year as well as export the relevant component.

These years, our company make great efforts to improve the technique of production through using advanced equipment.

Application

YH6003 Deutsch 6p male connector can be used in J1708 CAN BUS diagnostic unit (for trucks), J1708 body builder CAN bus monitor (for trucks), J1708 interface industrial engine display unit, ISOBUS-control devices, can bus Universal Controller, CAN gateway and bus simulator, truck diagnostic tool/equipment/scanner….

products specification
Connector Specification
Over molded color
Core color Grey
Core material PA66
Terminals' material

Body : Phosphor Bronze ; Sheel : steel

Terminals' Part No. YH AT60-201-1622
Terminals Applied Optical cable 20AWG-18AWG
Plug test over 10000 times
Advantages
Yeahui

● Yeahui Cable Limited specialized in producing connector more than 10years. All of our electronic connectors are customized.

● A lot of alternative connector produced on Yeahui according to Molex, Deutsch, Tyco, KET, DELPHI, Wabco, Sumitomo, LEAR…..

● Product creativities, superior quality, the process of integration, excellent before and after-sales service make us establish good and solid business relationship with our customer.

● Strict Quality Control System in Yeahui and all connectors and cables should be 100% inspected before dispatching.

● It is designed for the trailer end, and has finger hooks which allow for an easy connection and disconnection from the tow vehicle.
