OBDII Male 16pin Connector For Obdii Diagnostics Information Reader

Model Number: YH1001
Certification: ROHS, REACH
Minimum Order: 100pcs
Delivery Time: About 20days
Payment Terms: T/TWestern Union
Supply Ability: 20000 pieces per month

Features

YH1001 obd2 connector J1962 16 pin obd2 plug (12V) is widely used in OBD II scanner, EOBD universal diagnostic tester, automotive diagnostic tool.

We are specialized in obd2 connector(OBDII male connector, OBDII female connector, OBDII 90° right-angle connector, obdii 90° connector for PCB...)

This obdii male plug is used to connect to your vehicle and Female is ideal for making an extension cable or some apparatus.

There are various type of OBDII connector in Yeahui company, such as over molding obd2 connector 12V, over molded obdii diagnostic connectors 24v,obd2(J1962) brass golden plated PCB soldered obd2 plug, right-angle obdii male connector, obd2 male connector with soldered.

YH1001 16 pin male connector's (12V) plug test over 50000 times and the cable blending testing life over 10000 times.

Advanced equipment and quality process technique make YH1001 OBDII plug superior flexibility and durability.

Prompt respond will be get from us when we received any questions about YH obd2(J1962) connectors

Application

YH1001 16 pin obdii male connector is used on widely fields. Such as Automotive, military, aerospace and Industrial,data communication, medical solutions. mobile network, factory automotion...The detail equipment are OBDII-CAN programming tools, GPS tracker, diesel engines optimization device, multi diagnostic scanner, EOBD universal diagnostic tester, multi diagnostic scanner , diesel injector test, ECU Programmer, EOBD/OBDII diagnostics information reader, OBD module Bluetooth…. It is based on board diagnostics standard and YH1001 J1962 OBD2 connector is used on large variety of cars.

products specification

The connector specification, wire specification, Electronic parameter of YH1002 16 pin male connector(24V) showed below.

Connector Specification
Over molded color Black & customized
Core color Black Red, Yellow, Green, Blue
Core material PBT(POCAN)
Terminals' material Brass Pre-Tin
Terminals' Part No. YH 6618343BSS
Terminals Applied Optical cable 26AWG-18AWG
Plug test over 50000 times
Wire Specification
Cable length 200mm & customized
Cable jacket PVC,PUR and Customized
Cable pin out Customized
Cable cross-section AWG 26-20 available
Cable Bending testing life over 10000 times
Electronic parameter
Withstand Voltage 300V DC
Insulation Resistance Over 2MΩ
Rated current 1A ~ 5A
Contact Resistance MAX 1Ω (L≤3M)
Wire Rated temperature -20 ~ 105 ℃
Advantages
Yeahui

● Yeahui is one of the cutomize cable manufacturers that manufacturing on board diagnostic connector for more than 10 years.

● Our factory have obtained the TUV/ISO 9001:2015 international standard quality management

● There are strong R&D department support us to design qualified J1962 obd2 connector.All products are produced according to approved DWG.

● 4.PVC, PUR and customized cable jacked for YH1001 16 pin obdii plug available

● The cable length and pin out of YH1001 J1962 obd2 diagnostic connector are customized.

● YH1001 obd2 connector conform to Reach & RoHS certificated.

● The wire of YH1001 obd2 plug(12V) compliance with UL standard.
